Material:SUS304
Standard length:100mm~1200mm,or customized
Installation:SAE 5 holes with 6pcs M5 screws, gasket .The sleeve(p38mm) could be removed and cleaned
Waterproof grade:lP67
Rated power:125mW
Output siqnal:0-190Ω(Standard),240-330(Standard) or customzied,or current output like 0~20mA.4~20mA.0r voltage output like 0.5-4.5VDC.0-5VDC
Working temperature:-40~+85°
Application:All tanks for engine/cars/boats,etc
Accuracy:10mm,20mm,21mm(Default)
Cable:Standard lengthis 460mm,PVC(0.75mm2),or customized
